Hardware

• • Drivers:
    Satellites: 7.6 cm polished aluminum phase plug drivers
    Subwoofer: 25.4 cm high-excursion ported driver with 6th order bass reflex enclosure
    Surround sound effects
  • Hardware decoding:
    Dolby® Digital, DTS®, and DTS®, 96/24 soundtracks
    Dolby Pro Logic II (Movie and Music modes)
    6 Channel Direct
    Stereo x2
    Stereo
  • Supported digital formats:
    Dolby Digital
    DTS and DTS 96/24
    PCM (uncompressed stereo): 44.1 kHz / 16 bit through 96 kHz / 24 bit
  • Source Inputs:
    Digital optical for DVD or CD players, PlayStation®2, Xbox®**
    Digital coaxial for DVD or CD players or PC sound cards (requires coaxial cable, sold separately)
    6 channel direct (3 stereo-mini connectors) for 2, 4, or 6 channel PC sound cards OR
    6 channel direct (3 stereo-mini connectors) for 3 stereo analog mini audio sources, like CD and DVD players, Playstation 2, Xbox, or 2 channel PC sound cards (somedevices may require stereo mini to dual RCA adapter, sold separately)
    Analog stereo-mini (on side panel of control center) for portable CD, MP3,or MiniDisc® players

Technical Specifications

• • Total FTC power: 505 watts RMS
    Sub-woofer: 188 watts RMS (into 8 ohms, @ 100Hz, @ 10% THD)
    Satellites:
    Left/Right: 62 watts RMS x 2 (into 8 ohms, @ 1khz, @ 10% THD)
    Center: 69 watts RMS (into 8 ohms, @ 1kHz, @ 10% THD)
    Rear Left & Right: 62 watts RMS x 2 (into 8 ohms, @ 1kHz, @ 10% THD)
  • Total Peak power: 1010 watts
  • Maximum SPL: >115 dB
  • Frequency response: 33 Hz 20 kHz
  • Amplifier: Ultra-linear, high-capacity analog
  • Signal to noise ratio: >93.5 dB, typical 100
  • Input impedance: 8,000 ohms
  • Compatibility:
    PC/Mac
    CD
    MP3
    DVD
    PlayStation®
    Xbox®
